Pixel Light Controller RGB RGBW LED DIY with Remoter
FEL-CP1 is a compact yet powerful LED dream color controller, featuring touch keys and a digital tube display for easy operation, with RF remote control up to 30-50 meters. It supports all IC-driven LED lights, including RGB/RGBW pixel strips, with 6 IC options and adjustable pixel control. Offering various dynamic lighting effects, users can customize brightness, speed, color change direction, RGB sequence, and DIY effects. With an input voltage of DC5V-24V, max 10A output current, and power range of 50W-240W, it meets diverse needs.
Highlights
→ Supports RGB/RGBW, 6 ICs.
→ Touch keys, digital display.
→ RF control, 30-50m range.
→ DIY brightness, effects.
→ 10A, 50-240W range.
| Model | Pixel Light Controller RGB RGBW DIY FEL-CP1 |
| Working Voltage | DC5V-DC24V |
| Output Current | Max 10A |
| Output Power Range | 50W(5V)/120W(12V)/240W(24V) |
| Remote Distance | 30-50m |
| Controller Dimension | L135 X W30 X H20(mm) |
| Weight | 110g |
Send Your Inquiry
Highly Versatile: Supports RGB and RGBW pixel strips, compatible with 6 IC series, and allows customizable pixel counts for needs ranging from small decor to big projects.
User-Friendly: Features touch keys and a digital tube display for intuitive setup, plus RF remote control with a 30-50 meter range for convenient adjustments anytime, anywhere.
Fully Customizable: Adjust brightness, speed, color change direction, and RGB sequences, or DIY unique effects to unleash endless creativity.
Broad Compatibility: Handles DC5V-24V input voltage and up to 10A output current, reliably powering various LED setups for diverse applications.
Cost-Effective: Compact yet powerful, it blends practicality and personalization, making it an ideal choice for both home users and professionals.
Q: What types of LED strips does FEL-CP1 support?
A: FEL-CP1 supports RGB and RGBW pixel strips and is compatible with 6 common IC series (e.g., WS2811, SK6812). Users can select the appropriate IC setting based on their strip type for proper operation.
Q: How far is the remote control range, and do obstacles affect it?
A: The remote range is 30-50 meters. The RF signal can penetrate some barriers, but walls or large obstacles may reduce the effective distance. For best results, use it in open spaces.
Q: What should I do if the pixel strip doesn’t light up after connection?
A: Check if the input voltage matches the strip (DC5V-24V), ensure the pixel count is set correctly, and verify secure connections. If it still doesn’t work, the IC type might be incorrect—adjust the settings accordingly.
Q: Can it control multiple strips at once?
A: Yes, but the total pixel count and output current (max 10A) must stay within limits. Connect strips in parallel and ensure the power supply has sufficient capacity.
Q: How do I save DIY lighting effects?
A: DIY effects on FEL-CP1 are adjusted in real-time and cannot be permanently saved. Users need to reconfigure their custom effects each time they use it.
Home Decoration: Ideal for living rooms, bedrooms, or patios, with dynamic effects and DIY colors for holidays (e.g., Christmas, Halloween) or daily ambiance.
Commercial Spaces: Perfect for cafes, restaurants, or shop windows, using flexible lighting control to attract customers and boost brand appeal.
Stage Performances & Events: Powers RGB/RGBW strips to create dazzling effects synced with music or event themes.
DIY Projects: Meets the needs of enthusiasts and creators for art installations, model lighting, or custom lighting designs.
Indoor & Outdoor Use: Suitable indoors or outdoors (with waterproofing), adapting to various environments.
| Model | Pixel Light Controller RGB RGBW DIY FEL-CP1 |
| Working Voltage | DC5V-DC24V |
| Output Current | Max 10A |
| Output Power Range | 50W(5V)/120W(12V)/240W(24V) |
| Remote Distance | 30-50m |
| Controller Dimension | L135 X W30 X H20(mm) |
| Weight | 110g |
Send Your Inquiry
Highly Versatile: Supports RGB and RGBW pixel strips, compatible with 6 IC series, and allows customizable pixel counts for needs ranging from small decor to big projects.
User-Friendly: Features touch keys and a digital tube display for intuitive setup, plus RF remote control with a 30-50 meter range for convenient adjustments anytime, anywhere.
Fully Customizable: Adjust brightness, speed, color change direction, and RGB sequences, or DIY unique effects to unleash endless creativity.
Broad Compatibility: Handles DC5V-24V input voltage and up to 10A output current, reliably powering various LED setups for diverse applications.
Cost-Effective: Compact yet powerful, it blends practicality and personalization, making it an ideal choice for both home users and professionals.
Q: What types of LED strips does FEL-CP1 support?
A: FEL-CP1 supports RGB and RGBW pixel strips and is compatible with 6 common IC series (e.g., WS2811, SK6812). Users can select the appropriate IC setting based on their strip type for proper operation.
Q: How far is the remote control range, and do obstacles affect it?
A: The remote range is 30-50 meters. The RF signal can penetrate some barriers, but walls or large obstacles may reduce the effective distance. For best results, use it in open spaces.
Q: What should I do if the pixel strip doesn’t light up after connection?
A: Check if the input voltage matches the strip (DC5V-24V), ensure the pixel count is set correctly, and verify secure connections. If it still doesn’t work, the IC type might be incorrect—adjust the settings accordingly.
Q: Can it control multiple strips at once?
A: Yes, but the total pixel count and output current (max 10A) must stay within limits. Connect strips in parallel and ensure the power supply has sufficient capacity.
Q: How do I save DIY lighting effects?
A: DIY effects on FEL-CP1 are adjusted in real-time and cannot be permanently saved. Users need to reconfigure their custom effects each time they use it.
Home Decoration: Ideal for living rooms, bedrooms, or patios, with dynamic effects and DIY colors for holidays (e.g., Christmas, Halloween) or daily ambiance.
Commercial Spaces: Perfect for cafes, restaurants, or shop windows, using flexible lighting control to attract customers and boost brand appeal.
Stage Performances & Events: Powers RGB/RGBW strips to create dazzling effects synced with music or event themes.
DIY Projects: Meets the needs of enthusiasts and creators for art installations, model lighting, or custom lighting designs.
Indoor & Outdoor Use: Suitable indoors or outdoors (with waterproofing), adapting to various environments.
